    25FT Q355 Steel Material Galvanized Electric Power Steel poles

    Ask Lasest Price
    Brand Name : JSBS
    Model Number : Q355
    Certification : ISO9001:2008
    Price : USD 30-300 per piece
    Payment Terms : T/T, L/C
    Supply Ability : 200 pcs per day
    Delivery Time : within 30 working days
    • Product Details
    • Company Profile

    25FT Q355 Steel Material Galvanized Electric Power Steel poles

    25FT Q355 Steel Material Galvanized Electric Power Steel poles


    Description:

    Our low voltage electric steel poles have been mainly exported to Philippines, South America, South Africa since 2005.


    Steel Pole of National Electrification Administration

    (PHILIPPINES)

    Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT,45FT

    Height

    (ft)

    Thickness

    (mm)

    Butt Diameter

    (mm)

    Top

    Diameter

    (mm)

    Design

    Load

    (kg)

    Yield

    Stress

    (MPA)

    Zinc

    Coating

    (microns)

    252.515212030034586
    303.022612750034586
    353.024812750034586
    403.031712750034586
    454.032812775034586

    Material
    Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.

    China-GBAmerica-ASTMEquivalent
    Q235Grade DSS400,S235JO
    Q345Grade50[345]S355JR
    Q420Grade60[415]S420NL
    Q460Grade65[450]S460NL


    FAQ:
    1. We are the direct factroy and trading company. Our office and factory address: Industrial Zone, Heqiao Town, Yixing District, Wuxi City, Jiangsu Province, China (mainland).


    2. Port of Loading: Shanghai or as request

    3. Price term: EXW,FOB,CFR, CIF.

    4. MOQ: 1 piece


    5. Payment Term: 30%TT in deposit, 70%TT before shipment. Or LC.

    6. Delivery: Based on your order quantity. Normally 15 days after receiving your deposit.


    Our Service:

    1. Reply your inquiry in 24 working hours.

    2. Experienced staffs answer all your questions in fluent English.


    3. We provice OBM and ODM service.


    4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.


    5. Special discount and protection of sales are provided to our distributors.


    6. Professional factory : We are the direct manufacturer, specialized in producing all kinds of steel poles since 2005 with competitive price and good quality.


    7. Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.


    8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.


    Factory Profile

    Founded in 2005, Jiangsu Baojuhe Science and Technology Co.,Ltd ( previous name Jiangsu Bosheng Steel Poles Co.,Ltd) is located in Heqiao Town Industrial Zone, Yixing District, Wuxi City, Jiangsu Province, China.


    Baojuhe is the specialized manufacturer of various steel poles and steel components including street lighting poles, electric power poles, traffic signal poles, flag poles, wind power poles and microwave communication towers, etc.


    Through Shanghai Port, which is one of the largest ports in China, we export poles to South America, Middle East, Africa, Australia, Philippines and other countries.
