    3.0mm ~ 20mm Thickness Polygonal High Voltage Electric Steel Utility Pole

    Ask Lasest Price
    Brand Name : JSBS
    Model Number : BS/SU - 01
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T,, Western Union
    Supply Ability : 2000 Ton per month
    Delivery Time : 15 - 25 work days
    • Product Details
    • Company Profile

    3.0mm ~ 20mm Thickness Polygonal High Voltage Electric Steel Utility Pole

    Specification


    Material
    Applied to the material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.

    China-GBAmerica-ASTMEquivalent
    Q255Grade DSS400,S235JO
    Q355Grade50[345]S355JR
    Q420Grade60[415]S420NL
    Q460Grade65[450]S460NL

    Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shearing machine, cutting machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with best quality.

    After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.


    Inspection


    To ensure the quality, we have professional engineers to inspect the poles during the manufacturing and before delivery.
    We have Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, etc.

    3.0mm ~ 20mm Thickness Polygonal High Voltage Electric Steel Utility Pole


    Galvanized Electric Steel Utility Pole in High Voltage


    TypeStraight Pole ,Tensile Pole ,Turn Pole
    Shape of poleRound / Conical / Polygonal

    Material

    Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345 ,Q460 used in China.

    Q235 equivalent to SS400, S235JO.

    Q345 equivalent to S355JR,Grade 50

    Q460 equivalent to S460, Grade 65

    Wall thickness2.5mm to 20mm
    WeldingWelding complies with CSA and AWS standard and our welders have got corresponding certificate after testing and inspection.
    JointingJoint with flange mode
    GalvanizingHot dip galvanized with thickness of min 86 microns on average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.
    Max Wind Speed30m/s
    Max Ice10mm
    CertificatesISO9001:2008 ; SGS ; AAA credit rating, etc
    Warranty20 years




    FAQ


    1. Are you a manufacturer or a trading company?

    A:We are the direct factory manufacturer and the trading company.


    2. Where is your company located?

    A:Our factory is located in Industrial Zone No.37, Heqiao Town, Yixing District, Wuxi City, Jiangsu Province, China(mainland).


    3. What are your main products?

    A:Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.


    4. What's your nearest port?

    A: Shanghai Port is our nearest port.


    5. What's your payment term?

    A: Normally 30% deposit and rest by TT before shipping. Or L/C.


    6. What's your delivery time?

    A: Normally within 20 working days. If our factory is busy and your quantity is large, then around one month.


    7. What's your price term?

    A: Price Term: EXW, FOB, CFR or CIF.


    EXW: Poles Cost

    FOB: Pole Cost + Land Transportation + Fee on Port

    CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight

    CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.


    Factory Profile


    Jiangsu Baojuhe Science and Technology Co.,Ltd. (previous name Jiangsu Bosheng Steel Poles Co.,Ltd.) is located in Heqiao Town Industrial Zone, Yixing District, Wuxi City, Jiangsu Province, China.

    Baojuhe is the specialized manufacturer of various steel poles and steel components including street lighting poles, electric power poles, traffic signal poles, flag poles, wind power poles and microwave communication towers, etc.

    Through Shanghai Port, which is one of the largest ports in China, we export poles to South America, Middle East, Africa, Australia, Philippines and other countries.
