Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install

Jiangsu Baojuhe Science and Technology Co.,Ltd
Contact Now
    Buy cheap Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install from wholesalers

    Buy cheap Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install from wholesalers
    • Buy cheap Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install from wholesalers
    • Buy cheap Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install from wholesalers
    • Buy cheap Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install from wholesalers

    Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install

    Ask Lasest Price
    Brand Name : JSBS
    Model Number : BS/RL - 04
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : D/P, Western Union, L/C, T/T
    Supply Ability : 2000 Ton per month
    Delivery Time : 15 - 25 work days
    • Product Details
    • Company Profile

    Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install

    Conical Octagonal Galvanized Parking Lot Light Pole Lam Pole for Square


    Specification

    nameConical Octagonal Galvanized Parking Lot Light Pole Lam Pole for Square
    TypeParking Lot Light Pole
    Shapeconical, hexagonal and octagonal
    MaterialUsually Q345B/A572,minimum yield strength>=345n/mm2
    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460, ASTM573 GR65, GR50, SS400, SS490ST52
    Tolerance of dimension+-2%
    Design Load in Kg300~ 1000 Kg appliced to 50cm from the to pole
    Surface treatmentHot dip galvanized Following ASTM A 123, Or powder coated.
    StandardOctagonal Conical tapered column
    Certified by SIRIM QAS INTERNATIONAL.
    Approved by JABATAN KERJA RAYA MALAYSIA.
    Conforms to Standard:
    Pole design: BS EN 40
    Material: BS EN 10025 S275 / JIS G3101 SS400
    Welding: BS 5135
    Galvanizing : BS 729 / ISO 1461 ASTM A 123
    Parking Lot Light pole suit forcity square, wharf, stadium, Parking Lot, Road, Street, Garden, etc
    Option of Light poleHeight from 6m to 12m
    Flange mounted or Burial type



    Description

    1. Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
    (Other Materials are Available as required)
    2. Hot Dip Galvanized (≥86um)
    3. Any Color Polyester Powder Coated (≥100 um)
    4. Taper Conical, Octagonal, Polygon Section
    5. With demounted bracket design,easy loaded,install and maintenance
    6. Theftproof slide lock
    7. Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,


    Production Process

    - Material preparation
    - Bending
    - Welding
    - Repair and grinding
    - Reforming
    - Flushing
    - Fix bottom plate
    - Welding bottom plate
    - Opening door
    - Welding door strip, electric strip, and locking
    - Bending arm
    - Hot dip galvanization
    - Plastic powder painted
    - Inspection
    - Delivery




    Quality Control Management

    Our company processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.

    Meanwhile, it has formed a scientific and strict quality management system, which effectively and strictly guarantees the quality control of products form raw material to finished products.

    The rate of pass of street light pole is 98%. Smooth installation and complete match. The rate of customer satisfaction is 95%,



    Terms and Conditions
    1. Price Term: EXW, FOB, CFR or CIF.

    Ø EXW: Poles Cost
    Ø FOB : Pole Cost + Land Transportation + Fee on Port
    Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
    Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

    2. MOQ: One 40FT Container.
    3. Payment Term: Typically 30% by T/T as a deposit, balance by T/T or L/C at sight before shipment. Other
    payment way can be negotiated.
    4. Delivery Time: 15 working days per container after PI/drawing/ prepayment confirmed.
    5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’
    requirement.


    Company Information

    Through the efforts of the company staff, the support and cooperation from all over the world. Baojuhe's steel poles have been exported to the Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World per day on average.

    Quality Hexagonal shape parking lot poles , parking lot lamp post With Base Plate Install for sale
