Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post

Jiangsu Baojuhe Science and Technology Co.,Ltd
Contact Now
    Buy cheap Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post from wholesalers

    Buy cheap Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post from wholesalers
    • Buy cheap Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post from wholesalers
    • Buy cheap Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post from wholesalers
    • Buy cheap Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post from wholesalers

    Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post

    Ask Lasest Price
    Brand Name : JSBS
    Model Number : BS/RL - 5
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : D/P, Western Union, L/C, T/T
    Supply Ability : 2000 Ton per month
    Delivery Time : 15 - 25 work days
    • Product Details
    • Company Profile

    Single / Double arm galvanized light pole 20 W- 400 W Lamp Power Square Light post

    Galvanized Round Tapered 6m - 11M Outdoor Parking Lot Light Poles


    Specification

    Height6 m to 11 m
    ApplicationSquare, Parking Lot, Road ,Street, Highway, etc
    ShapeConical , polygonal , Round
    Lamp Power

    20 W- 400 W (HPS/MH)

    220V (+-10%) /50Hz

    ArmSingle or Double
    Lighting FixtureIP 65
    Working Atmosphere of Lighting Fixture-35 °C~+45 °C
    Surface TreatmentHot dip galvanized with ASTM A 123
    SafetyAgainst earthquake of 8 grade
    Wind Speed160 Km/Hour
    Min Yield Strength355 mpa
    Min Ultimate Tensile Strength490 mpa
    Max ultimate tensile strength620 mpa
    StandardISO 9001 : 2008
    Thickness2.5 mm to 30 mm
    MaterialSteel Q235, Q345, SS400, S355JR,etc
    Powder CoatedColor as request



    Description

    1. Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
    (Other Material is Available on Request)
    2. Hot Dip Galvanized (≥86um)
    3. Any Color Polyester Powder Coated (≥100 um)
    4. Taper Conical , Octagonal, Polygon Section
    5. With demounted bracket design,easy loaded,install,and maintenance
    6. Theftproof slide lock
    7. Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,


    Production Process

    - Material preparation
    - Bending
    - Welding
    - Repair and grinding
    - Reforming
    - Flushing
    - Fix bottom plate
    - Welding bottom plate
    - Opening door
    - Welding door strip, electric strip, and locking
    - Bending arm
    - Hot dip galvanization
    - Plastic powder painted
    - Inspection
    - Delivery




    Quality Control Management

    Our company processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.

    Meanwhile, it has formed a scientific and strict quality mangement system, which effectively and strictly guarantees the quality control of products form raw material to finished products.

    The rate of pass of street linght pole is 98%. Smooth installation and complete match. The rate of customer satisfaction is 95%,




    Terms and Conditions


    1. Price Term: EXW, FOB, CFR or CIF.

    Ø EXW: Poles Cost
    Ø FOB : Pole Cost + Land Transportation + Fee on Port
    Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
    Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

    2. MOQ: One 40FT Container.


    3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other
    payment way can be negotiated.


    4. Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.


    5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom,or according to clients’
    requirement.


    Company Information

    Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World in average every day.
