Jiangsu Baojuhe Science and Technology Co., Ltd. (previous name Jiangsu Bosheng Steel Poles Co.,Ltd)
10 Years
| Ask Lasest Price | |
| Brand Name : | JSBS |
| Model Number : | BS/RL - 03 |
| Certification : | ISO9001:2008 |
| Price : | Negotiation |
| Payment Terms : | D/P, Western Union, L/C, T/T |
| Supply Ability : | 2000 Ton per month |
| Delivery Time : | 15 - 25 work days |
9M High Mast Tapered Galvanized Parking Lot Light Pole IP 65 White
Surface Color
Specification
| name | 9M High Mast Tapered Galvanized Parking Lot Light Pole IP 65 White Surface Color |
| Type | Parking Lot Light Pole |
| Shape | conical, hexagonal and octagonal |
| Material | Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52 |
| Tolerance of dimension | +-2% |
| Design Load in Kg | 300~ 1000 Kg appliced to 50cm from the to pole |
| Surface treatment | Hot dip galvanized Following ASTM A 123, Or powder coated. |
| Standard | Octagonal Conical tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design: BS EN 40 Material: BS EN 10025 S275 / JIS G3101 SS400 Welding: BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123 |
| Parking Lot Light pole suit for | city square, wharf, stadium, Parking Lot, Road, Street, Garden, etc |
| Option of Light pole | Height from 6m to 12m Flange mounted or Burial type |
Description
- Material preparation
- Bending
- Welding
- Repair and grinding
- Reforming
- Flushing
- Fix bottom plate
- Welding bottom plate
- Opening door
- Welding door strip, electric strip, and locking
- Bending arm
- Hot dip galvanization
- Plastic powder painted
- Inspection
- Delivery
1. Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2
Tensile Strength: 375-460Pa 38-47kg/mm2
(Other Materials are Available on Request)
2. Hot Dip Galvanized (≥86um)
3. Any Color Polyester Powder Coated (≥100 um)
4. Taper Conical , Octagonal, Polygon Section
5. With demounted bracket design,easy loaded,install,and
maintenance
6. Theftproof slide lock
7. Category: Street lighting pole, Garden Lighting pole Solar
Street lighting pole, High Mast,highmast light poles,
Terms and Conditions
1. Price Term: EXW, FOB, CFR or CIF.
Ø EXW: Poles Cost
Ø FOB : Pole Cost + Land Transportation + Fee on Port
Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea
Freight + Insurance.
2. MOQ: One 40FT Container.
3. Payment Term: Typically 30% by T/T as a deposit, balance by T/T or L/C at sight
before shipment. Other
payment way can be negotiated.
4. Delivery Time: 15 working days per container after PI/drawing/ prepayment
confirmed.
5. Package: Normally wrapped by plastic bags or burlap cloth at the top and
bottom, or according to clients’
requirement.
Factory Profile
Jiangsu Baojuhe Science and Technology Co.,Ltd. (previous name
Jiangsu Bosheng Steel Poles Co.,Ltd.) is located in Heqiao Town
Industrial Zone, Yixing District, Wuxi City, Jiangsu Province,
China.
Baojuhe is the specialized manufacturer of various steel poles and
steel components including street lighting poles, electric power
poles, traffic signal poles, flag poles, wind power poles and
microwave communication towers, etc.
Through Shanghai Port, which is one of the largest ports in China,
we export poles to South America, Middle East, Africa, Australia,
Philippines and other countries.
|
|
